The JST 06R-JWPF-VSLE is a complete, factory-assembled wire-to-wire harness from the JST JWPF Series. This part number represents a specific, pre-configured assembly that provides a robust, IP67-rated waterproof and dustproof connection straight out of the package. Designed for applications exposed to moisture, vibration, and harsh conditions, it eliminates the complexity of manual sealing and crimping, ensuring maximum reliability and consistency.

Key Features & Benefits:

Pre-Assembled & Sealed (IP67): Arrives as a ready-to-install unit with integrated seals, providing immediate protection against water immersion (up to 1m for 30 mins) and dust ingress, eliminating assembly errors.

JWPF Series Reliability: Part of JST's renowned line of compact, sealed connectors, known for their robust performance in automotive and industrial settings.

Secure Double-Lock Mechanism: Features both a primary terminal lock and a secondary housing lock (Connector Position Assurance - CPA), ensuring terminals remain seated and the connector pair remains fully mated under extreme vibration.

Pre-Defined Configuration: This specific part denotes a 6-position (6-pin) wire-to-wire assembly, where both ends are typically identical plugs, creating an in-line extension or connection.

Durable Construction: The housing is made from high-temperature resistant PBT material, and the seals are made from high-grade silicone rubber, capable of withstanding automotive under-hood temperatures and harsh chemicals.

Precision Crimping: Factory-crimped with the correct JST terminals and wires, guaranteeing optimal electrical performance and mechanical strength.

Applications:

This sealed harness is essential in applications where environmental sealing is critical:

Automotive Systems: Sensor connections (e.g., wheel speed, temperature), lighting, body control modules, and in-vehicle infotainment wiring.

Outdoor & Powersports: Wiring for ATVs, motorcycles, marine electronics, and agricultural machinery.

Industrial Automation: Equipment in wash-down areas, outdoor control cabinets, and robotic actuators.

Appliance: Connections in white goods that may be exposed to moisture or condensation.

Technical Specifications:

Manufacturer Part Number: 06R-JWPF-VSLE

Series: JST JWPF

Connector Type: 6-Position, Sealed Wire-to-Wire Assembly (Plug to Plug)

Sealing Rating: IP67

Number of Positions: 6

Wire Gauge: Specific AWG to be confirmed (Commonly 20-22 AWG)

Temperature Range: -40°C to +105°C+ (Typical for automotive)

Contact Plating: Tin

Housing Material: PBT

Seal Material: Silicone Rubber

Compatible Mating Part:

This harness is designed to mate with an identical JST 06R-JWPF-VSLE harness or a compatible JWPF receptacle.

Ordering Information:

The JST 06R-JWPF-VSLE is a standard, off-the-shelf pre-assembled and sealed harness.
